Image EC
Please visit the store for more information or call us at: (905) 828-1980
Description
- Includes interchangeable color shrouds in red and blue.
- Front suspension system for extra-smooth ride.
- Available with full-size Captain’s Seat in 18″ or 20″ widths.
- Height-adjustable swivel seat features fold-down backrest.
- Seat back reclines and features adjustable headrest.
- Adjustable-length controller mount.
- Armrests are padded, adjustable and removable.
- Optional swing-away controller arm (Item #SF1009) sold separately.
- Adjustable, flip-up footplate.
- Positioning belt included.
- Optional elevating leg rests (requires Item #ECELR-P,
- Item #SFELR & Item #LK3JELR) sold separately.
- Flat-free, non-marking tires.
- Easy free-wheel operation.
- Easy access to batteries from the rear of the chair. (Figure A)
Please visit the store for more information or call us at: (905) 828-1980
Specifications
Specifications
| HCPCS | K0823 |
|---|---|
| Weight Capacity | 300 lbs. |
| Top Speed | 4 mph |
| Maximum Range | 15 miles |
| Turning Radius | 27.5″ |
| Climbing Angle | 6° |
| Ground Clearance | 2″ |
| Dimensions | 42″ (L) x 24″ (W) |
| Floor-to-Seat Height | 20″ – 23″ |
| Seat Dimensions | 18″ (W) x 18″ (D) | 20″ (W) x 18″ (D) |
| Controller | PG VR2 50A |
| Motors (2) | 24V x 200W x 3900 rpm |
| Batteries (pair) | 12V x 35AH (U1) |
| Charger | 4A Offboard |
| Brakes | Electromagnetic |
| Caster Wheels | 6″ x 2″ Solid |
| Drive Wheels | 10″ x 3″ Flat-free |
| Base Weight | 88 lbs. |
| Battery Weight (pair) | 53 lbs. |
| Seat Weight | 51 lbs. |
| Total Weight | 192 lbs. |
| Warranty on Frame | Lifetime |
| Warranty on Electronic Controller/Drive Train Components | 14 Months |
| Warranty of Batteries | 6 Months |
Downloads
Downloads
Owners Manual
Catalog Page
Parts Diagram
Order Form
Products
Products
| Item # | Seat | HCPCS* | UOM | |
|---|---|---|---|---|
| 2800ECBU-RCL | Select | 18″ Captain’s Seat | K0899, K0823 | 1/cs |
| 2800ECBU-RCL-20 | Select | 20″ Captain’s Seat | K0823 | 1/cs |
Order Now!
Order Now!
[gravityform id=”1″ title=”false” description=”false”]
Parts
Parts
| Diagram Number | Part Description | Part Number | |
|---|---|---|---|
| 1 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19132/form_key/fej3As1llEwzA6eg
Head Rest, Image EC,1/ea
|
Head Rest 18″ | ECI6015 |
| 1 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19133/form_key/fej3As1llEwzA6eg
Headrest 20,Image EC Seat,1/ea
|
Head Rest 20″ | ECI6015-20 |
| 2 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19134/form_key/fej3As1llEwzA6eg
Seat 18 inch, Image EC,1/ea
|
Seat 18″ | ECI6005 |
| 2 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19135/form_key/fej3As1llEwzA6eg
Seat 20 inch, Image EC,1/ea
|
Seat 20″ | ECI6004 |
| 3 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/18860/form_key/fej3As1llEwzA6eg
JoystickTip,PG Controller,1/ea
|
Joystick Tip | CP6200T |
| 4 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19051/form_key/fej3As1llEwzA6eg
Joystick, VR2, Grey Plug, 1/ea
|
Joystick | S350169701 |
| 5 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/18861/form_key/fej3As1llEwzA6eg
ContrllrScrewSet,P&G,VSI,1/ea
|
Joystick Screws | SI69001 |
| 6 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19136/form_key/fej3As1llEwzA6eg
ImageGT,ControllerBracket, 1/cs
|
Joystick Arm | GTI6045 |
| 7 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19130/form_key/fej3As1llEwzA6eg
Seat Plate, Image EC,1/ea
|
Seat Plate | ECI6007 |
| 8 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19131/form_key/fej3As1llEwzA6eg
Wire Harness, Sunfire GT Plus, 1/ea
|
Wire Harness | SF9038GT |
| 9 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19137/form_key/fej3As1llEwzA6eg
SHROUD, IMAGE EC,1/EA
|
Shroud | ECI6011 |
| 10 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19138/form_key/fej3As1llEwzA6eg
Footrest,SunfirePlus,1/ea
|
Footplate | SF9035 |
| 11 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19139/form_key/fej3As1llEwzA6eg
Front or Rear caster, Image EC, 1/ea
|
Front & Rear Caster | ECI6040 |
| 12 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19140/form_key/fej3As1llEwzA6eg
FORK, IMAGE EC,1/EA
|
Fork | ECI6020 |
| 13 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19141/form_key/fej3As1llEwzA6eg
VR2 Controller, ECI, Grey Plug, 1/ea
|
Controller For Yellow Plug REV2 ** | S350169738 |
| 14 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19142/form_key/fej3As1llEwzA6eg
SUSPENSION, IMAGE EC,1/EA
|
Suspension | ECI6025 |
| 15 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19143/form_key/fej3As1llEwzA6eg
FENDER SHROUD BUR R, IMAGE EC,1/EA
|
Fender Shroud-Burgundy Right | ECI6010BUR |
| 15 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19144/form_key/fej3As1llEwzA6eg
FENDER SHROUD BUR L, IMAGE EC,1/EA
|
Fender Shroud-Burgundy Left | ECI6010BUL |
| 15 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19145/form_key/fej3As1llEwzA6eg
FENDER SHROUD BLUE R, IMAGE EC,1/EA
|
Fender Shroud-Blue Right | ECI6010BR |
| 15 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19146/form_key/fej3As1llEwzA6eg
FENDER SHROUD BLUE L, IMAGE EC,1/EA
|
Fender Shroud-Blue Left | ECI6010BL |
| 16 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19147/form_key/fej3As1llEwzA6eg
RearTire,Gray,SunfirePlus,1/ea
|
Drive Wheel | SF9060 |
| 17 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19148/form_key/fej3As1llEwzA6eg
MOTOR RIGHT, IMAGE EC,1/EA
|
Motor | ECI6018R |
| 17 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19149/form_key/fej3As1llEwzA6eg
MOTOR LEFT, IMAGE EC,1/EA
|
Motor | ECI6018L |
| 18 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19150/form_key/fej3As1llEwzA6eg
ImageGT, Seat Post, 1/ea
|
Seat Post | GTI6006 |
| 19 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/18871/form_key/fej3As1llEwzA6eg
35AH (U1) Battery 1/ea
|
Batteries (ea. 2 needed) | LRA402208 |
| 24 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19156/form_key/fej3As1llEwzA6eg
Arm Pad Sunfire GT,1/ea
|
Arm Pad | SF9007GT |
| 25 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19157/form_key/fej3As1llEwzA6eg
BATTERY COVER, IMAGE EC,1/EA
|
Battery Cover | ECI6012 |
| 26 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19158/form_key/fej3As1llEwzA6eg
REAR FRAME, IMAGE EC,1/EA
|
Rear Frame | ECI6043 |
| 27 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19159/form_key/fej3As1llEwzA6eg
FORK PIVOT FRAME, IMAGE EC,1/EA
|
Fork Pivot Frame | ECI6030 |
| 28 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19160/form_key/fej3As1llEwzA6eg
DRIVE AXLE NUT, IMAGE EC,1/EA
|
Drive Axle Nut | ECI6018 |
| 29 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19161/form_key/fej3As1llEwzA6eg
ImageGT,Fork Stem Cap, 1/ea
|
Fork Stem Cap | GTI6044 |
| 30 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/18806/form_key/fej3As1llEwzA6eg
24Wheel Bearing,SentraXW,1/ea
|
Rear wheel bearing | STDS2A5303 |
| 31 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19162/form_key/fej3As1llEwzA6eg
Center Shrouding,Image EC,1set/pkg
|
Center Shroud | ECI6013 |
| 32 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19163/form_key/fej3As1llEwzA6eg
FRONT FRAME, IMAGE EC,1/EA
|
Front Frame | ECI6042 |
| 33 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19164/form_key/fej3As1llEwzA6eg
Caster Axle,ImageEC,1ea
|
Caster Axle | ECI6039 |
| 34 | Select
http://www.drivemedical.com/b2b/index.php/sap/cart/add/uenc/aHR0cDovL3d3dy5kcml2ZW1lZGljYWwuY29tL2IyYi9pbmRleC5waHAvaW1hZ2UtZWMtNTYzLmh0bWw,/product/19165/form_key/fej3As1llEwzA6eg
Caster Bearings Set,1pair
|
Caster Bearings | ECI6041 |
