Cobalt

Please visit the store for more information or call us at: (905) 828-1980

Category: Tag:

Description

  • Full-size performance in a lightweight, easily transportable power wheelchair.
  • Quick and easy disassembly. (Figure A)
  • Height-adjustable swivel seat features fold-down backrest.
  • Armrests are padded, adjustable and removable.
  • Adjustable-length controller mount.
  • Optional swing-away controller arm (Item #AA4100) sold separately.
  • Adjustable, flip-up footplate.
  • Optional elevating leg rests (requires Item #AE2500 & Item #LK3JELR) sold separately.
  • Positioning belt included.
  • Armrest-mounted reflectors.
  • Programmable controller.
  • Flat-free, non-marking tires.
  • Easy free-wheel operation.
  • Anti-tip wheels.

Please visit the store for more information or call us at: (905) 828-1980

Specifications

HCPCS KO821
Weight Capacity 250 lbs.
Top Speed 4 mph
Maximum Range 8 miles
Turning Radius 29″
Climbing Angle 6°
Ground Clearance 2″
Dimensions 38.5″ (L) x 24″ (W)
Floor-to-Seat Height 20″ – 23″
Seat Dimensions 18” (W) x 15” (D)
Controller Dynamic Shark 40A
Motors (2) 24V x 120W x 4700 rpm
Batteries (pair) 12V x 21AH
Charger 2A Offboard
Brakes Electromagnetic
Caster Wheels 8″ x 2″ Solid
Drive Wheels 9″ x 3″ Flat-free
Base Weight 74 lbs.
Battery Weight (pair) 28 lbs.
Seat Weight 19 lbs.
Total Weight 121 lbs.
Heaviest Piece Weight 52 lbs. (Front Section)
Warranty on Frame Lifetime
Warranty on Electronic Controller/Drive Train Components 14 months
Warranty on Batteries 6 months

Downloads

Owners-Manual

Owners Manual

Catalog-Page

Catalog Page

image-flat

Parts Diagram

image-flat

Start Guide

image-flat

Order Form

Products

Item # Color Seat HCPCS* UOM
COBALTBL16FS Select

Blue 18″ Folding Seat K0821 1/cs
COBALTRD16FS Select

Red 18″ Folding Seat K0821 1/cs

Parts

cobalt-parts

Diagram Number Part Description Part Number
1 Select Joystick Overlay DC GLA81043
2 Select Gear Box Assm.- Left LDR420002-05
2 Select Gear Box Assm.- Right LDR420002-06
3 Select 20 Amp Circuit Breaker LRM302107
4 Select Battery (order 2) LRM412123
5 Select Charger LRM302111
6 Select Fork Stem Bearings LDR410006-01
7 Select Caster Fork Assm. LDR420006
8 Select Front Caster Grey LDR420007
8 Select Front Caster Black LDR420007-02
9 Select Rear Wheel- Grey LDR420008
9 Select Rear Wheel- Black LDR420008-02
10 Select Frame Lock Bolt Assm. LDR420010
11 Select Anti-Tip Wheel LRC402410
12 Select Seat Assm. LDR420011-01
13 Select Shroud — Front Shroud Blue LDR420012-01B
13 Select Front Shroud Red LDR420012-01R
13 Select Rear Shroud Blue LDR420012-02B
13 Select Rear Shroud Red LDR420012-02R
14 Select Footrest Assm. LDR410016
18 Select Joystick Arm LDM400001-04
18a Select Joystick Screws LDM400001-01
19 Select Joystick Bracket LDM400001-05
20 Select Arm Assm.- Left LDR420016L
20 Select Arm Assm.- Right LDR420016R
21 Select Seat Post 17.96mm * LRM412100-13
22 Select Battery Cable LDR420000-01
23 Select Dust Cap LDM400013-02
24 Select Front Articulating Bar LDR420000-26
25 Select Wiring Harness LDR420000-12
26 Select Handle LDR420000-19
27 Select Contact Block Set LDR420001
28 Select Front Frame LDR420002
29 Select Battery Bag LDR420003-01
Select Shroud Knob LDR410115-03 (1L Serial #)
