Titan
Please visit the store for more information or call us at: (905) 828-1980
Description
- Height-adjustable swivel seat features fold-down backrest.
- Includes interchangeable color panels in red and blue.
- Seat back reclines and features adjustable headrest.
- Adjustable-length controller mount.
- Armrests are padded, adjustable and removable.
- Available with 18” or 20” Captain’s Seat.
- Optional swing-away controller arm (Item #AA4100) sold separately.
- Adjustable, flip-up footplate.
- Positioning belt included.
- Optional elevating leg rests (requires Item #AE2500 & Item #LK3JELR) sold separately.
- Programmable controller.
- Flat-free, non-marking tires.
- Easy freewheel operation.
- Anti-tip wheels.
Please visit the store for more information or call us at: (905) 828-1980
Specifications
Specifications
| HCPCS (Full Capt. Seat | Standard Capt. Seat) | K0823 | K0821 |
|---|---|
| Weight Capacity | 300 lbs. |
| Top Speed | 4 mph |
| Maximum Range | 15 miles |
| Turning Radius | 25″ |
| Climbing Angle | 6° |
| Ground Clearance | 2.5 |
| Dimensions | 40″ (L) x 25″ (W) |
| Floor-to-Seat Height | 20.5″ – 23″ |
| Captain’s Seat Dimensions | 18″ (W) x 18″ (D) | 20″ (W) x 18″ (D) |
| Controller | Dynamic Shark 40A |
| Motors (2) | 24V x 200W x 3900 rpm |
| Batteries (pair) | 12V x 35AH (U1) |
| Charger | 3A Offboard |
| Brakes | Electromagnetic |
| Caster Wheels | 6″ x 2″ Solid |
| Drive Wheels | 10″ x 3″ Flat-free |
| Base Weight | 68 lbs. |
| Battery Weight (pair) | 44 lbs. |
| Seat Weight | 43 lbs. |
| Total Weight | 158 lbs. |
| Warranty on Frame | Lifetime |
| Warranty on Electronic Controller/Drive Train Components | 14 months |
| Warranty on Batteries | 6 months |
Downloads
Downloads
Owners Manual
Catalog Page
Parts Diagram
Start Guide
Order Form
Products
Products
| Item # | Seat | HCPCS* | UOM | |
|---|---|---|---|---|
| TITAN18CS | Select | 18″ x 18″ Captain Seat, Full Back | K0821 | 1/cs |
| TITAN20CS | Select | 20″ x 18″ Captain Seat, Full Back | K0821 | 1/cs |
| TITANLB18CS | Select | 18″ x 18″ Captain Seat, Standard Back | K0821 | 1/cs |
| TITANLB18CSX23 | Select | 18″ x 18″ Captain Seat, Standard Back | K0823 | 1/cs |
| TITAN18CSX23 | Select | 18″ x 18″ Captain Seat, Full Back | K0823 | 1/cs |
| TITAN20CSX23 | Select | 20″ x 18″ Captain Seat, Full Back | K0823 | 1/cs |
