| Bed Height | 15″ – 26″ |
|---|---|
| Unit Dimensions | 36″ (W) x 87″ (L) |
| Weight | 135 lbs. |
| Carton Shipping Weight | 155 lbs. |
| Weight Limit | 450 lbs Maximum weight limit includes weight of occupant, all accessories such as mattress, side/assist rails, trapeze, any personal affects, etc. |
| Warranty | (Original purchaser) Limited Lifetime on welds and frame, 1 year on all parts and components |
| Item # | Product Description | HCPCS* | UOM | |
|---|---|---|---|---|
| 15601SD | Select | Spring Deck for Manual LTC Bed | E0293 | 1/cs |
| 15000HF | Select | Head and Foot Boards for LTC and Low Bed (Sold separately) | 1/cs |
| Diagram Number | Part Description | Part Number | |
|---|---|---|---|
| 1 | Select | Headboard | 15000H |
| 1a | Select | Set Head/Footboard | 15000HF |
| 2 | Select | Headboard Bracket | 15000H-B |
| 3 | Select | Leg | 15601-1L |
| 4 | Select | Leg Cap | 1560I-02 |
| 5 | Select | Pivot Bolt | 15601-04 |
| 6 | Select | Caster Insert | 15601-03 |
| 7a | Select | Caster Locking | 15601-00 |
| 7b | Select | Caster Non-locking | 15601-01 |
| 8 | Select | End Cap | 15601-05 |
| 9 | Select | Footboard Bracket Left | 15000F-BL |
| 9 | Select | Footboard Bracket Right | 15000F-BR |
| 10 | Select | Motor Cover | 15601-06 |
| 11a | Select | Handle | 15601-07 |
| 11b | Select | Bearing Plate | 15601-08 |
| 12 | Select | Footboard | 15000F |
| 13a | Select | Retainer | 15601-09 |
| 13b 1 | Select | Crank Screw Head | 15601-21 |
| 13b 2 | Select | Crank Screw Foot | 15601-22 |
| 13b 3 | Select | Crank Screw Hi/Low | 15601-23 |
| 13c | Select | Main Nut | 15601-10 |
| 13d | Select | Stop Clip | 15601-11 |
| 14 | Select | Torque Tube | 15601-12 |
| 14a | Select | Pin | 15601-13 |
| 15 | Select | Pivot Block Assm. | 15601-14 |
| 16 | Select | Spring Deck | 15601SD |
| 17a | Select | Top Spring | 15005-SPRING |
| 17b | Select | Side Spring | 15005-SPRING-1 |
| 18 | Select | U-Lever Frame | 15601-15 |
| 19 | Select | Flex Leg | 1560I-16 |
