Masonair 8″ Alternating Pressure and Low Air Loss Mattress System

Features

Alternating Pressure Mode has 10, 15, 20, 25 minute cycle times
Auto-Firm feature for max inflation when transferring patient and has auto-recovery after 30 minutes
CPR valve allows for rapid deflation
In case of a power failure the bottom 4″ air cell will remain inflated offering sufficient weight support for the patient
Lockout feature protects patient settings
Pillow Top feature keeps head and neck stable
Seat Inflation mode offers additional support when head of bed is raised for an extended period of time
Static Mode can suspend alternating mode and has auto-recovery after 30 minutes
The 10 adjustable comfort settings allows pressure to be customized by patient weight
The Masonair? AS8800 Alternating Pressure Mattress with Low Air Loss is one of the most advanced systems in the Masonair? series
The mattress consists of (20) 8″ high cell-on-cell designed air bladders
The microprocessor sensor technology provides continuous feedback to equalize pressure and maximize patient comfort
Visible and audible alarms with Alarm Mute feature (3minute auto-return feature)

Description

An Alternating Pressure Mattress System from Drive and Mason Medical is designed to aid in the prevention and treatment of pressure ulcers—also known as bed sores—by inflating and deflating air cells within the mattress in a regular pattern, offering pressure relief and improving air circulation. The Masonair AS8800 is one of the most advanced systems in the Masonair series, offering advanced microprocessor sensor technology, 10 adjustable comfort settings and a variety of alternating pressure cycles to maximize patient comfort. The AS8800 also adds Low Air Loss capability to the Alternating Pressure Mattress concept for a truly extraordinary therapeutic support surface.

Specifications

ControlUnit Airflow	8 LPM
Control Unit Cycle Time	10 , 15, 20, 25 Minutes
Control UnitType	Compressor
Control Unit Alarms	Visual / Audible
Mattress Dimensions	36″(W) X (80″, 84″L) X 8″(H)
Mattress Cover Material	Fluid-Resistant Nylon
Weight Capacity	350 lbs.
Warranty	1 Year Limited
